McCloskey TS4080 – 80FT Tracked Stacker | Rokbro Equipment NZ

Details
The McCloskey 8040T Tracked Stacker — also known as the TS4080 — is a heavy-duty, high-capacity mobile stockpiler designed to seamlessly integrate with mobile crushing and screening systems. With an 80-foot conveyor length and the ability to handle over 600 tonnes per hour, the 8040T offers unmatched flexibility, making it the ideal solution for efficient material transfer and bulk stockpiling across a range of industries. Built to reduce the need for loaders and double handling, this stacker improves site productivity while minimizing operational costs and setup time.

Key Features

  • High Throughput: Capable of over 600+ TPH, ideal for high-volume operations
  • Engine Performance: Powered by a reliable CAT 2.2 engine for efficient, low-maintenance operation
  • Large Stockpile Capacity: Creates stockpiles up to 11.33m (37’) high with a total capacity of 2,162 m³
  • Rugged Construction: Full-length skirting, hopper extensions with wear liners, and a heavy-duty frame for long-term durability
  • Optimized for Mobility: Easily moves on-site and integrates with crushers, screens, or directly into loadout systems
  • Fast Setup: Designed for quick deployment and minimal operator intervention

Applications and Performance

Ideal for:
  • Aggregates and quarry stockpiling
  • Bulk material handling at ports or terminals
  • Mobile recycling and crushing operations
  • Infrastructure and large-scale civil works
The 8040T significantly enhances operational efficiency by minimizing the need for additional equipment and maximizing continuous material flow.

Why Choose the McCloskey 8040T?

When you need serious stockpiling capacity combined with mobility and reliability, the McCloskey 8040T delivers. Designed to handle large volumes with ease, it’s the go-to tracked stacker for operators who want to increase uptime, reduce material handling costs, and streamline site logistics — all while maintaining a small operational footprint.
CAPACITY Operating Rate 600+ TPH*
CAPACITY Full Length Skirting YES
CAPACITY Hopper Extensions with wear liners YES
CAPACITY Stockpile Capacity 2162 m3
CAPACITY Stockpile Height 11,330mm (37’)
CAPACITY Engine CAT 2.2
download full tech spec
Load Sensing Pumps
E-SERIES MACHINES
WIRELESS REMOTE CONTROL
KEESTRACK-ER REMOTE MONITORING
Load Sensing Pumps
Load Sensing Pumps

A primary crusher with superior shaping ability, the R5 Impact Crusher fills a variety of roles using just one piece of equipment. The R5’s built in pre-screen’s, post-screens and recirculation conveyor ensures maximum product quality and throughput.

E-SERIES MACHINES
E-SERIES MACHINES

A primary crusher with superior shaping ability, the R5 Impact Crusher fills a variety of roles using just one piece of equipment. The R5’s built in pre-screen’s, post-screens and recirculation conveyor ensures maximum product quality and throughput.

WIRELESS REMOTE CONTROL
WIRELESS REMOTE CONTROL

A primary crusher with superior shaping ability, the R5 Impact Crusher fills a variety of roles using just one piece of equipment. The R5’s built in pre-screen’s, post-screens and recirculation conveyor ensures maximum product quality and throughput.

KEESTRACK-ER REMOTE MONITORING
KEESTRACK-ER REMOTE MONITORING

A primary crusher with superior shaping ability, the R5 Impact Crusher fills a variety of roles using just one piece of equipment. The R5’s built in pre-screen’s, post-screens and recirculation conveyor ensures maximum product quality and throughput.

// FAQs

frequently asked questions

Do I need a steel Apron feeder or a belt feeder on my scalping screen?

The general perception in NZ is a Steel apron feeder is better. This isn't always the case. In most applications a belt feeder scalping screen is better than a apron feeder. The only application where a steel apron feeder comes into its own is sharp rock or feeding large material from the quarry face. In river alluvial rock, topsoil & Compost, sand or small material (200mm-) applications a belt feeder is a far better option.

Is a Jaw/Cone or a closed circuit impactor better?

There's a lot of variables in this. Are you a contractor who moves from site to site often? What is your main product from a revenue point of view- Could you use a Jaw/Cone 90% of the time and possibly hire an impactor for 1 month of the year to cover demand for certain products? What is your fines content? What's your required throughput? What's your feed size?   Alot of New Zealand have tunnel vision for impact crushers because old mate down the road has one. Remember every quarry is different. We would advise to try a cone crusher if you ever have an opportunity. Don't take someone else's word for it. Where a cone doesn't work for one quarry it may be perfect for another. Think of your long term costs. Initial capital expenditure may be more yes but blow bars are not cheap. There's a reason why all the major quarries in New Zealand run with a Jaw/Cone set up.

Do i need a stacker for my operation?

In short, yes you do. You may not know it as you've never had one. If you have the space for a stacker, take our advise and buy/hire one. Thank us later. The general comment after some buys a stacker is "I should have bought this years ago". As the old saying goes, its the cheapest loader you'll ever buy. Yes of course you still need to pick the material up to load trucks but you would be shocked at the amount of diesel you'll save and the pressure if takes off a loader operator. The downside to stackers, particular on larger material is segregation. There is ways to mitigate this problem. If you have any questions talk to our team.
